JYPW-S series six-chamber household RO water purifier booster pump

share
WeChat
Sina Weibo
QQ
QQ space
Facebook
X
LinkedIn
Specification

JYPW-S series six-chamber booster pump is mainly used in household RO water purifier, automatic water vending machine,

On high-throughput models such as commercial water purifiers.

Product parameters:

Operating voltage: 24VDC/36VDC
Working pressure: 0.7mpa
Working flow: 4.0-5.5 L/min
Sealing pressure: 0.85-1.15mpa


Product Features:

  1. The number of working chambers is optimal under the same volume, which improves the vibration of the pump.
  2. Optimize the internal structure, reduce the flow loss and discharge loss;
  3. A rectifying mechanism is added in the flow passage to effectively reduce the impact of high-pressure water flow on the pipeline and improve the noise of the whole machine.


water purifier RO booster pump
